CAT6E Specifications - 4 Twisted Pairs (8 Conductors)
- 23 AWG Solid Bare Copper Conductors - NOT THE CHEAP CCA YOU WILL SEE FROM OTHER SELLERS!
- Rated to 600Mhz
- Superior signal to noise ratio
- Certified Transfer Rate: 10/100/1000 Mbps (1000Base-T Gigabit)
- CMR (RISER RATED) - Riser Rating is a flame test rating - CMR is a higher rating than CM or CMX, so be careful not to overpay for a cheaper cable from other sellers!!!
- Twisted pairs are brightly colored and distinguishable at a glance
- Whites are striped to match corresponding color pairs
- Comes standard with ripcord to assist in stripping PVC jacket
- Smooth jacket for easy pulling in tight spaces
- Length marked every two feet, so you always know how much is left in the box
- UL or ETL Listed
RG6 Quadshield Specifications
- 18 Gauge (AWG)
- CCS (Copper Clad Steel) Conductor
- CMR rated
- Ideal for satellite tv, digital cable, surveillance systems, and more
- Sweep tested to 3 GHz! Important for carrying the weaker signals produced by satellite
- Quad Shielding (two foils and two braids) prevents signal interference
- UL or ETL Listed
|
